Hardox® 550
Hardox® 550 Stockholder & Supplier
MTL Advanced Ltd is one of the largest Hardox® Weaparts Centre’s in the UK and is a Hardox® 550 stockholder/supplier to clients in a range of industries around the world, such as recycling and mining.
With various industry quality accreditations and many years’ experience working with this steel, we have the capability to manufacture and supply Hardox® 550 in different sizes and thicknesses to satisfy the needs of our customers.
Due to our extensive in-house manufacturing capabilities and stringent quality measures, we can also machine, press parts up to 7.2m length and waterjet cut Hardox® 550 to the UK’s highest standards.
Hardness (HBW, from thicknesses 8.00 - 65.00mm):
525 - 575
Impact Properties (Longitudinal test, Typical Impact energy, Charpy V 10 x10 mm test specimen):
30 J / -40 C
C (max %): 0.37
Si (max %): 0.50
Mn (max %): 1.30
P (max %):0.020
S (max %): 0.010
Cr (max %): 1.40
Ni (max %): 1.40
Mo (max %): 0.60
B (max %): 0.004
Thickness 8.00 - 65.00mm: Max CET(CEV) = 0.51 (0.76) | Typ CET(CEV) = 0.48 (0.72)
Fabrication and other recommendations
Welding, bending and machining Recommendations can be found in SSAB’s brochures at www.hardox.com or consult Tech Support, help@ssab.com.
Hardox® 550 is not intended for further heat treatment. It has obtained its mechanical properties by quenching and when necessary by means of subsequent tempering. The properties of the delivery condition cannot be retained after exposure to temperatures in excess of 250ºC.
Appropriate health and safety precautions must be taken when welding, cutting, grinding or otherwise working on this product. Grinding, especially of primer coated plates, may produce dust with a high particle concentration.
What is Hardox® 550?
Hardox® 550 is a Q&T martensitic wearplate for applications that demand high resistance to abrasion, such as hammers, shredders and cutters for the recycling industry.
The wear plate significantly extends service life, but not at the expense of crack integrity, and cuts maintenance costs.
MECHANICAL PROPERTIES
Thickness (mm) – 8.00-65.00
Hardness* (HBW) – 525-575
*Brinell hardness, HBW, according to EN ISO 6506-1, on a milled surface 0.5– 3 mm below surface. At least one test specimen per heat and 40 tons. The nominal material thickness will not deviate more than ± 15 mm from that of the test specimen.
